Keychron K10 Pro QMK/VIA Wireless Mechanical Keyboard allows anyone to master any keyboard keys or macro commands through VIA, it has included keycaps for both Windows and macOS, and users can hot-swap with any MX mechanical switch in a breeze.

Keychron

K10 Pro

A 100% layout QMK/VIA wireless custom mechanical keyboard

Keychron K10 Pro QMK/VIA Wireless Mechanical Keyboard Fully assembled or Barebone version

Wireless and Wired

An excellent solution for multitasking. You can connect the K10 Pro with up to 3 devices wirelessly via its stable Broadcom Bluetooth 5.1 for seamless multitasking across your laptop, phone, and tablet. Switch among them swiftly, and it’s fully compatible with both Mac and Windows.

A reliable USB Type-C wired connection is also available when you need it.

Keychron K10 Pro QMK/VIA Wireless and Wired Mechanical Keyboard on the desk

Program with QMK & VIA.

QMK/VIA means endless possibilities for a fluid workflow.
Simply connect the K10 Pro to your device with a cable, drag and drop your favorite keys or macro commands to remap any key you want on any system (macOS, Windows, or Linux).

Check out the video above demonstrating how to remap the F16 key (located on the K10 Pro’s top right corner) to an Eject key with the VIA software, so you can get a shortcut to put your Mac to sleep (Command-Option-Eject), or even remap the fn key in a breeze. It’s never been so intuitive and flexible to personalize your own keymap.

An ultra-low-power ARM Cortex-M4 32-bit STM32L432 MCU which is powerful, and equipped with 128K Flash will provide more flexibility for developers.

Download VIA for Mac Download VIA for Windows Download VIA for Linux

Get the keymap working on VIA

Since the VIA code for the K10 Pro is still awaiting approval from Github, it is not yet automatically recognized, so you will need to manually download and import the K10 Pro keymap.

Please download the keymap JSON file below. Connect your keyboard and device with the provided cable, and toggle the switch to cable mode. Open VIA, click on the "Show Design tab" on the "Settings" tab, enable "Use V2 definitions (deprecated)" on the "Design" tab, and drag the JSON file into the “Design” tab on VIA to get the K10 Pro keymap working on VIA.

K10 Pro Keymap JSON Files

Download K10 Pro ANSI white backlight keymap JSON file

Download K10 Pro ANSI RGB keymap JSON file

Learn more about how to use VIA >

Upgraded Typing Experience

The K10 Pro has been re-engineered and redesigned from the inside out to upgrade the typing experience. The added sound-absorbing foam, a thick silicone dampening bottom pad, and steel plate provide responsive feedback and a peaceful typing sound, while added weight will enhance the stability.

An Epic Core of Keychron K10 Pro keyboard

An Epic Core Inside The Keyboard

A powerful ultra-low-power ARM architecture MCU equipped with 128K Flash will provide more flexibility for developers. The polling rate is 1000 Hz out of the box, which makes latency non-existent for the competitive game.

Suitable For All Devices

Offers a Mac layout while still being compatible with Windows, the K10 Pro is one of the few on the market that has the same multimedia and function keys as Apple keyboards for Mac users, but with more tactile feedback.

You can even configure different keymaps for both Mac and Windows devices. While VIA software is compatible with macOS, Windows, and Linux. Includes keycaps for both macOS and Windows (3 keycaps for each) to allow you to switch between operating systems with ease.

Hot-swappable

Every detail matters, so we make the K10 Pro hot-swappable for your personalized typing experience. The hot-swappable sockets are mounted on the PCB, so you can hot-swap every switch on the K10 Pro with almost all of the 3pin and 5pin MX style mechanical switches on the market (including Cherry, Gateron, Kailh, Panda, etc.) without soldering. You can customize your own typing experience in seconds.

Barebone US layout of Keychron K10 Pro QMK VIA wireless mechanical keyboard

Screw-In PCB Stabilizers

Even small part matters for your fingertip feel. We’ve integrated the PCB-mounted screw-in stabilizers for a smoother typing experience with less wobbliness on the big keys such as space bar, shift, enter, and backspace. The Keychron K10 Pro also supports third-party screw-in PCB stabilizers.

Keychron K10 Pro PCB Screw-in stabilizers

Pre-lubed Keychron K Pro Switch

By optimizing the switch mold, the K Pro switch wobbles less than a standard mechanical switch and feels smoother on each hit. Plus, the factory pre-lubed process on all the K Pro switches (exclude the clicky ones), no doubt this will ensure the best smoothness at your fingertips when typing.

Keychron K Pro mechanical switch features

OSA Profile Double-shot PBT Keycaps

To further fine-tune your typing experience, the K10 Pro comes with our unique OSA profile (OEM profile with spherical-angle) and double-shot PBT keycaps that aim to provide a more comfortable fingertip feel with excellent oil resistance for long-term use on the timeless tenkeyless layout.

South-facing RGB Lights

The south-facing RGB is designed to better illuminate the keyboard backlight from the typist’s angle. The south-facing RGB is also free from interference when the user installs Cherry-profile alternative keycaps on their keyboard.

Comes with more than 22 types of RGB backlight settings (as well as a static white backlight option), and 14 types of backlight settings on the White Backlight version. You can further fine-tune the RGB hue, saturation, brightness, effect speed with ease.

Ergonomic Support

Three levels of adjustable typing angle (3.5º, 7º & 10.5º) and curved OSA-profile keycaps are all working together to provide long-lasting ergonomic support for your wrist.

Keychron K10 Pro ergonomic support with adjustable typing feet and angle

What's in the box?

Keychron K10 Pro package content-fully assembled version

SPECIFICATION

Number of Keys: 108 (100%)
Switches (Not including Barebone Version): Keychron K Pro Mechanical
Switch Face: South-facing
Stabilizers: PCB-mounted screw-in stabilizers
Number of Multimedia Keys: 12
Frame Material: ABS
Plate Material: Steel
Keycap Material (excluding Barebone Version): Double-shot PBT (backlight non-shine-through)
Keycap Profile: OSA (OEM profile with spherical-angle)
Layout: ANSI
Polling Rate (Wired Mode): 1000Hz
Polling Rate (Wireless Mode): 90Hz
N-Key Rollover (NKRO): Yes for both wireless and wired modes

CONNECTIVITY AND POWER

Backlit: 22 types of RGB backlight options plus endless possibilities
Battery: 4000 mAh rechargeable li-polymer battery
BT Working Time (Backlit off): Up to 300 hours (Lab test result may vary by actual use)
BT Working Time (RGB): Up to 100 hours (Lowest brightness)
Connection: Bluetooth and Type-C cable
Bluetooth version: 5.1
Bluetooth Device Name: Keychron K10 Pro
Compatible System: macOS/Windows/Linux

PHYSICAL UNIT

Dimension: 445 x 138 mm (17.52 x 5.43")
Weight: About 1495 g / 3.29 lbs
Height without keycap (front): 23.2 mm (0.91")
Height without keycap (rear): 30.8 mm (1.21")
Height incl. keycap (front): 32.8 mm (1.29")
Height incl. keycap (rear): 40.4 mm (1.59")
Typing Angle: 3.5º, 7º and 10.5º
MCU: Ultra-low-power ARM Cortex-M4 32-bit STM32L432 (128KB Flash)
Operating Environment: -10 to 50℃

Keychron K10 Pro User Guide

Learn more about the Keychron K10 Pro such as the shortcuts, VIA tutorial, factory reset, and more in the FAQ section.
